Standard Edition USB DAC Amp with 3.5mm and 4.4mm Outputs

Upgrade your audio experience with the TANCHJIM LUNA USB DAC/Amp – Standard Version. Engineered with dual CS43198 DAC chips and a high-precision amplifier system, this compact audio interface delivers crystal-clear playback, deep detail, and exceptional dynamic range. Built for audiophiles and everyday users alike, the LUNA supports ultra-high-resolution decoding up to 32-bit/768kHz and DSD256. With a durable aluminum housing and versatile output options, it's the perfect choice for portable, high-fidelity sound—whether at home or on the move.

Key Features

• Dual CS43198 DAC chips for reference-grade audio clarity

• Portable design with durable aerospace-grade aluminum casing

• Supports 32-bit/768kHz PCM and DSD256 decoding

• Selectable Class AB and Class H amplification modes

• Versatile connectivity with 3.5mm and 4.4mm output ports

• Detachable Type-C cable with high-quality shielding and conductors

• Extremely low noise floor and minimal distortion for pure sound

Specifications

• Input: USB Type-C

• Output: 3.5mm Single-Ended, 4.4mm Balanced

• Frequency Response: 8Hz – 80kHz

• PCM: 32-bit / 768kHz

• DSD Support: DSD256

• Dynamic Range: 132dB (Balanced), 127dB (Unbalanced)

• Signal-to-Noise Ratio: 132dB (Balanced)

• THD+N: 0.00014% (Balanced)

• Output Power: 175mW @ 16Ω, 285mW @ 32Ω, 54mW @ 300Ω (Balanced)

• Output Levels:

  • Balanced High: 4 Vrms

  • Balanced Low: 2 Vrms

  • Unbalanced High: 2 Vrms

  • Unbalanced Low: 1 Vrms

• Noise Floor: 1.3 µV (Balanced), 1 µV (Unbalanced)

Package Contents

• 1 x TANCHJIM LUNA USB DAC/Amp – Standard Version

• 1 x High-Quality Silver-Coated USB-C Cable

• 1 x User Manual

Note:
This item is in pre-order status. Orders will be shipped sequentially after the pre-order period. Please extend processing time accordingly. Cancellation is not available once the order is placed.
